ASTM A554 316 304 Square Steel Tubing / Durable Astm Stainless Steel Pipe

China ASTM A554 316 304 Square Steel Tubing / Durable Astm Stainless Steel Pipe supplier
ASTM A554 316 304 Square Steel Tubing / Durable Astm Stainless Steel Pipe supplier ASTM A554 316 304 Square Steel Tubing / Durable Astm Stainless Steel Pipe supplier ASTM A554 316 304 Square Steel Tubing / Durable Astm Stainless Steel Pipe supplier ASTM A554 316 304 Square Steel Tubing / Durable Astm Stainless Steel Pipe supplier ASTM A554 316 304 Square Steel Tubing / Durable Astm Stainless Steel Pipe supplier

Large Image :  ASTM A554 316 304 Square Steel Tubing / Durable Astm Stainless Steel Pipe

Product Details:

Place of Origin: China
Brand Name: TORICH
Certification: ISO9001:2008, ISO14001:2008, TS16949
Model Number: ASTM A554

Payment & Shipping Terms:

Minimum Order Quantity: 1 tons
Price: negotiable
Packaging Details: In hexagonal bundles or wooden box
Delivery Time: 5-6 weeks
Payment Terms: L/C, T/T, D/A, D/P
Supply Ability: 20000 tons per year
Contact Now
Detailed Product Description
Standard: ASTM A554 Material: Stainless Steel
Shape: Round Manufacture: Welded, Square, Rectangle Or Special Shape
Dimension: OD ≤406.4mm, WT ≥0.51mm

ASTM A554 316 304 Stainless Steel Welded Pipe / Square Steel Tubing





As-welded or cold-reduced mechanical tubing.



Shapes:

Round, Square, Rectangle, or special.



Dimension:

OD ≤406.4mm

WT ≥0.51mm



Grade:

MT-301,  MT-302, MT-304, MT-309S

MT-310S, MT-316, MT-316L, MT-317

MT-321, MT-347, MT-430, MT-430i



Materials and Manufacture:

The tubes are manufactured from flat-rolled steel by automatic welding process.



Delivery Condition:

1.  As welded

2. Welded and annealed

3. Cold reduced

4. Cold reduced and annealed



Inside diameter bead:

a. Bead not removed

b. Bead controlled to 0.005 in. (0.13mm) or 15% of the specified wall thickness, whichever is greater

c. Bead removed





Type one: Pickling Pipe

Size: OD:0.23''-80''(5.8-2032mm)

WT:0.01''-1.125''(0.25-28mm)



ANSI/ASME size as under,

NPS:1/8''-80'' SCH:5/5s,10/10s,20/20s,40/40s,80/80s,120/120s,160/160s acc. to ANSI B36.19/36.10

other standard of size is for ready choice.

Length: according to clients' request.

Standard:JIS DIN GB BS ASTM(ASME) etc.



Surface Finish: Annealed,Polish,Brush etc.

Application:for fluid and gas transport structure and machining.

Packing:Plywood cases or bundles.



Type two: Bright Annealed Tube

Size: OD range:6-50.8mm WT range:0.71-3.68mm Length:6-24m

Standard:ASTM A249, EN 10217-7, etc



Process Method:Welded ,bright annealed.

Surface Finish:Bright Annealed(BA),pickling,bright annealed(BA)&polish



Packing:

In bundles with outside protection and seaworthy packing

Wooden box, crate, cartons, with a lifts on the bundles for easy loading and unloading





ASTM A554 316 304 Square Steel Tubing / Durable Astm Stainless Steel Pipe ASTM A554 316 304 Square Steel Tubing / Durable Astm Stainless Steel Pipe

ASTM A554 316 304 Square Steel Tubing / Durable Astm Stainless Steel PipeASTM A554 316 304 Square Steel Tubing / Durable Astm Stainless Steel Pipe

Table 1 Dimension in millimeters

Tube outside diameter Thickness

12

12.7

17.3

21.3

1

1

1

1

25

33.7

38

1.2 1.6

1.2 1.6

1.2 1.6

40

51

63.5

1.2 1.6

1.2 1.6

1.6

70

76.1

88.9

1.6

1.6

2

101.6

114.3

139.7

2

2

2

168.3

219.1

273

2.6

2.6

2.6

323.9

355.6

406.4

2.6

2.6

3.2





Bibliography:

ISO 1127:1992 Stainless steel tubes - Dimensions, tolerances and conventional masses per unit length



ISO 2604-2:1975 Stainless products for pressure purposes - Quality requirements - Part 2: Wrought seamless tubes



ISO 2604-5:1987, Steel products for pressure purposes - Quality requirements Part 5: Longitudinally welded austenitic stainless steel tubes



ISO 4200:1991, Plain end steel tubes, welded and seamless - General tables of dimensions and masses per unit length





SUPPLEMENTARY REQUIREMENTS:

S1  Hardness Test

S2  Tension Test

S3  Nondestructive Test

S4  Test Report





Referenced Documents:

ASTM Standards:

ASTM A370    Test Methods and Definitions for Mechanical Testing of Steel Products

ASTM E30      Test Methods for Chemical Anaysis of Steel, Cast Iron, Open-Hearth Iron

                          and Wrought Iron

ASTM E 59        Practice for Sampling Steel and Iron for Determination of Chemical Composition



Military Standards:

MIL-STD-129    Marking for Shipment and Storage

MIL-STD-163    Steel Mill Products Preparation for Shipment and Storage



Federal Standard:

Fed. Std. No. 123   Marking for Shipments
