Boiler A213 Stainless Seamless Steel Tube/ 304 Stainless Steel Tubing Annealed Pickled

China Boiler A213 Stainless Seamless Steel Tube/ 304 Stainless Steel Tubing Annealed Pickled supplier
Boiler A213 Stainless Seamless Steel Tube/ 304 Stainless Steel Tubing Annealed Pickled supplier Boiler A213 Stainless Seamless Steel Tube/ 304 Stainless Steel Tubing Annealed Pickled supplier Boiler A213 Stainless Seamless Steel Tube/ 304 Stainless Steel Tubing Annealed Pickled supplier Boiler A213 Stainless Seamless Steel Tube/ 304 Stainless Steel Tubing Annealed Pickled supplier

Large Image :  Boiler A213 Stainless Seamless Steel Tube/ 304 Stainless Steel Tubing Annealed Pickled

Product Details:

Place of Origin: China
Brand Name: Torich
Certification: ISO9001
Model Number: ASTM A213

Payment & Shipping Terms:

Minimum Order Quantity: 1000kg
Price: 3000-6000 USD/TON
Packaging Details: In bundles in wooden box
Delivery Time: 3-4 weeks
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 5000tons per year
Contact Now
Detailed Product Description
Standard: ASTM A213 Grade: 304 316
Production: Cold Drawn Delivery Condition: Pickled And Annealed
Application: Boiler And Heat Exchanger Type: Straight And U Bend

A213 Stainless Seamless Steel Tube Annealed Pickled for Boiler / Heat Exchangers



Seamless Stainless Steel tubes For Boiler and Heat Exchanger, are made according to the Chinese National Standard GB13296-91.



GB13296-91 is a standard applicable for Seamless Stainless Steel pipes which is used for boiler and heat exchanger.



GB13296-1991 Seamless Stainless Steel Tubes for Boiler, Heat Exchangers

0Cr18Ni9 1Cr18Ni9Ti 0Cr18Ni12Mo2Ti



Technical tandard: GB13296-91



Tolerance for seamless stainless boiler tube:

Production Method Size(mm) Tolerance
Hot Rolling(Extrusion) OD ≤140 ±1.25%
>140 ±1.0%
WT ≤10 ±12.5%
>10 ±15%
Cold Drawn(Cold Rolled) OD 8~30 ±0.20mm
>30~50 ±0.30mm
>50 ±0.8%
WT 1.0~3

+12%

-10%

>3.0

±10%



Length:
The length or general steel tube:
Hot Rolling(Extrusion) tube: 3~12 m
Cold Drawn(Cold Rolled) tube: 3~8 m
The length for water pipe & boiler steel pipe:
Hot Rolling(Extrusion) tube: 4~12 m
Cold Drawn(Cold Rolled) tube: 4~8 m



Bending tolerance:

WT≤15mm, Bending≤1.5mm/m

WT>15mm, Bending≤2.0mm/m



End shape:

Both ends of the pipe should be cut at right angles, and remove burrs



Mechanical property

Heat treatment of longitudinal mechanical properties of steel pipe shall according to the standard.

Material

Tensile strength MPa

Yield Strength MPa

Elongation

%

0Cr18Ni9 520 205 35
1Cr19Ni9 520 205 35
0Cr19Ni10 480 175 35
1Cr18Ni9Ti 550 205 40
0Cr18Ni12Mo2Ti 530 205 35
0Cr26Ni5Mo2 590 390 18
1Cr17 410 245 20
00Cr27Mo 410 245 20
1Cr25Ti 440 245 17



Hardness:

For the tubes which W.T. ≥2 mm, Rockwell hardness tests should be taken.



Tests of the seamless boiler tubes:

1.Bending Test:

The tubes should take the bending test when OD ≤22mm. The bending angle is 90 degrees, and the bending radius is 6 times the outer diameter of the steel tube.



2. Hydraulic test;

Eddy current testing, ultrasonic testing can be used instead of hydraulic tests. When eddy current testing, GB/T 7735-1995 Gr. A should be followed; when ultrasonic testing, GB/T 5777-1996 Gr. C8 should be followed.

3. Flattening test

4. Flanging test

5. Expand test



 Boiler A213 Stainless Seamless Steel Tube/ 304 Stainless Steel Tubing Annealed PickledBoiler A213 Stainless Seamless Steel Tube/ 304 Stainless Steel Tubing Annealed Pickled

Boiler A213 Stainless Seamless Steel Tube/ 304 Stainless Steel Tubing Annealed Pickled

Boiler A213 Stainless Seamless Steel Tube/ 304 Stainless Steel Tubing Annealed Pickled
