Plain End Seamless Precision Steel Tube EN10305-1 E355 Bright Annealing

China Plain End Seamless Precision Steel Tube EN10305-1 E355 Bright Annealing supplier

Large Image :  Plain End Seamless Precision Steel Tube EN10305-1 E355 Bright Annealing

Product Details:

Place of Origin: China
Brand Name: Torich
Certification: ISO9001 ISO14001
Model Number: EN10305-1

Payment & Shipping Terms:

Minimum Order Quantity: 0.5tons
Price: 2000USD-3000USD/ton
Packaging Details: In wooden boxes packging
Delivery Time: 5-8 week days
Payment Terms: L/C, T/T
Supply Ability: 5000tons per year
Contact Now
Detailed Product Description
Material: E355 Standard: EN10305-1
Length: 12m Max End: Plain
Certificate: SGS BV Condition: Bright Annealing

EN10305-1 Precision Steel Tube , Hydraulic Cylinder Tubing cutting to Specified Length




Size range:

O.D.:6-380mm

W.T.:1-35mm

L:max12000mm

Steel Grade and Chemical Compositions:

Steel Grade C Si Mn P S Al
Steel Name Steel Number max max max max max min
E215 1.0212 0.10 0.05 0.70 0.025 0.025 0.025
E235 1.0308 0.17 0.35 1.20 0.025 0.025 -
E355 1.0580 0.22 0.55 1.60 0.025 0.025 -



Standard:

EN10305-1 Seamless Cold Drawn/Rolling Steel Tubes



Application:

For Hydraulic Cylinder/Oil Cylinder Tube/Excavator Chains and Parts



Mechanical properties at room temperature
Steel grade Minimum values for the delivery condition
Steel Name Steel Nubmer (+Cc) (+LCc) (+SR) (+Ad) (+N) NBK
Rm Mpa A % Rm Mpa A % Rm Mpa ReH Mpa A % Rm Mpa A % Rm Mpa ReH Mpa A %
E215 1.0212 430 8 380 12 380 280 16 280 30 290-430 215 30
E235 1.0308 480 6 420 10 420 350 16 315 25 340-480 235 25
E355 1.0580 640 4 580 7 580 450 10 450 22 490-630 355 22



aRm: tensile strength; ReH: upper yield strength; A: elongation after fracture
b 1Mpa=1N/mm2
c Depending on the degree of cold work in the finishing pass the yield strength may nearly be as high as the tensile strength.
For calculation purposes the following relations are recommended:
for delivery condition +C: ReH ≥0.8 Rm
for delivery condition +LC: ReH ≥0.7 Rm
d For calclulation purposes the following relation is recommended:ReH≥0.5Rm
e For tubes with outside diameter ≤30mm and wall thickness ≤3mm the ReH minimim values are 10Mpa lower than the values given in this Table
f For tubes with outside diameter>160mm: ReH≥420Mpa

Note: Special steel grade is also available, according to customer request.
