Incoloy 825 Alloy Steel Pipe Gr1 Gr2 Annealed And Pickled For Chemical

China Incoloy 825 Alloy Steel Pipe Gr1 Gr2 Annealed And Pickled For Chemical supplier
Incoloy 825 Alloy Steel Pipe Gr1 Gr2 Annealed And Pickled For Chemical supplier Incoloy 825 Alloy Steel Pipe Gr1 Gr2 Annealed And Pickled For Chemical supplier Incoloy 825 Alloy Steel Pipe Gr1 Gr2 Annealed And Pickled For Chemical supplier Incoloy 825 Alloy Steel Pipe Gr1 Gr2 Annealed And Pickled For Chemical supplier

Large Image :  Incoloy 825 Alloy Steel Pipe Gr1 Gr2 Annealed And Pickled For Chemical

Product Details:

Place of Origin: Zhejiang
Brand Name: TORICH
Certification: ISO
Model Number: Incoloy 825

Payment & Shipping Terms:

Minimum Order Quantity: 500 Kgs
Price: USD 50-55 Per Kg
Packaging Details: Anti Rust Oil Protection, in seaworthy packing
Delivery Time: 4-6 Weeks
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10 Tons Per Month
Contact Now
Detailed Product Description
Resistance (μΩ.m): Stable Ultimate Strength (≥ MPa): 550
Elongation (≥ %): 30 Material: Nickel Alloy
Type: Tubes Bars And Plates Density: 8.1g/cm3



Good Stress Corrosion Cracking Resistance Performance Incoloy 825 Bar and Tube Chemical use





Specifications



Diameter:12-300mm
Density : 8.1g/cm3
Materials: Inconel 600, 601, 625, 718, X750, Incoloy 901, 925, 926, etc

Best price inconel 825 pipe



Characteristic



1. Good stress corrosion cracking resistance performance
2. Good resistance for pitting and crevice corrosion performance
3. Good anti-oxidation and non-oxidzing heat acid performance
4. Good mechanical performance in both room temperature and up to 550°C
5. Have the pressure vessel authenticate when manufacture temperature up to 450°C



Corrosion resistance



825 is an all-purpose project alloy, have good corrosion resistance of the acid and alkali metal property

in both oxidation and reduction environments. High nickel content made it with effective stress corrosion

cracking resistance performance. 825 have excellent corrosion resistance in different kinds of media,

such as sulfuric acid, phosphoric acid, nitric acid and organic acid, alkali metal such as sodium hydroxide,

potassium hydroxide, and hydrochloric acid. A variety of media corrosion of nuclear-burning dissolver

show 825 high integrated prpperty, like sulfuric acid, nitric acid and potassium hydroxide are all dealing

in a same device.











  Grade



   UNS

                                                      Chemical ,%
          C    Cr    Ni     Fe       Al    Ti      Si             Mn



Incoloy 800



UNS N08800 0.10 max 19.0-23.0 30.0-35.0 39.50Min 0.15-0.60   1.00max 1.50max



Incoloy 810



UNS N08810 0.05-0.10 19.0-23.0 30.0-35.0 39.50Min 0.15-0.60 0.15-0.60



Incoloy 811



UNS N08811 0.06-0.10 19.0-23.0 30.0-35.0 39.50Min 0.25-0.60 0.25-0.60



Incoloy 825



UNS N08825 0.05 max 19.5-23.5 38.0-46.0 22.0Max 0.2max 0.60-1.20 0.50max 1.00max



Incoloy 825 Alloy Steel Pipe Gr1 Gr2 Annealed And Pickled For Chemical



Incoloy 825 Alloy Steel Pipe Gr1 Gr2 Annealed And Pickled For Chemical



Incoloy 825 Alloy Steel Pipe Gr1 Gr2 Annealed And Pickled For Chemical



Incoloy 825 Alloy Steel Pipe Gr1 Gr2 Annealed And Pickled For Chemical



Note :



Inconel 625 :



Gr1: Annealed at 871ºC min

Gr2:Solution annealed at 1090 ºC min with or without subsequent stabilization.



Available Size:



OD: 6.53-219.1 mm

WT: 0.89-12.7 mm

L: 20 meter Max



Available Specification :



ASTM B161 /B 163/ B 165/ B 167/ B 407/ B 423/ B 444/ B 751/ B 775/ B 829

ASTM SB161 /SB 163/ SB 165/ SB 167/ SB 407/ SB 423/ SB 444/ SB 751/ SB 775/ SB 829



Delivery Condition:



  1. Annealed and pickled
  2. Bright and Annealed
  3. Annealed and Pickled + Polishing
  4. Bright and Annealed + Polishing
