Product Details:
Payment & Shipping Terms:
|
| Standard2:: | DIN 2391, GB/T 8713 | Grade Group:: | 10#-45#, 16Mn, Q195-Q345 |
|---|---|---|---|
| Thickness:: | 2 - 30 Mm | Outer Diameter(Round):: | 30 - 250 Mm |
| Application:: | Hydraulic Pipe | Secondary Or Not:: | Non-secondary |
| Special Pipe:: | Thick Wall Pipe | Surface Treatment:: | As Client's Request |
API, ASTM,DIN standard carbon cylinder steel tube
Commodity Specifications:
1.Commodity name:st52 mechanical properties precision cylinder steel pipes
2.Standard:GB/T8713,GB/T3639,DIN2391,EN10305,ASTMA519,ASTMA106-2006
3.Grade: 10#(St37/St37.2/St35.8),20#(aisi1020,ck20,St42-2/St45-8/St45-4),
45#(aisi1045,ck45,ASTM A1045),st52(16Mn,Q345D),25Mn(stkm13c-t),27SiMn
4.OD:30-250mm;
5.ID tolerance:H8,H9,H10
8. Delivery condition:BK,BKW,BKS,GBK,NBK
9.Package: steel strip bundles, black paint coating, beveled ends or plain
10.Payment Terms: L/C or T/T(30% deposit and 70% balance against B/L copy)
11.Price Item:EXW,FOB,CFR or CIF
12.Delivery Time: Usually 15 working days after order confirmed& getting T/T deposit or original L/C
Michanical Performance
| Delivery Condition | Cold drawn+ stress-relieved(BK+S)(SR) | Cold fished (hard)(BK) | |||
| Steel Grade |
Tensile strength (Rm Mpa) |
Yield strength | Elogation A5% |
Tensile strength (Rm Mpa) |
Elogation A5% |
| 20# |
≥ 520
|
≥ 375 | ≥ 15 | ≥ 550 | ≥ 8 |
| 45# | ≥ 600 | ≥ 520 | ≥ 10 | ≥ 640 | ≥ 5 |
| E355(Q345B,St52) | ≥ 600 | ≥ 520 | ≥ 14 | ≥ 640 | ≥ 5 |
| 25Mn | ≥ 600 | ≥ 510 | ≥ 15 | ≥ 640 | ≥ 5 |
| 27SiMn | ≥ 800 | ≥ 610 | ≥ 10 | ≥ 800 | ≥ 5 |
ID Tolerance:
| ID size | ID deviation (mm) | |||
| H7 | H8 | H9 | H10 | |
| 30 |
+0.021 0 |
+0.033 0 |
+0.052 0 |
+0.084 0 |
| >30~50 |
+0.025 0 |
+0.039 0 |
+0.062 0 |
+0.100 0 |
| >50~80 |
+0.030 0 |
+0.046 0 |
+0.074 0 |
+0.120 0 |
| >80~120 |
+0.035 0 |
+0.054 0 |
+0.087 0 |
+0.140 0 |
| >120~180 |
+0.040 0 |
+0.063 0 |
+0.100 0 |
+0.160 0 |
| >180~250 |
+0.046 0 |
+0.072 0 |
+0.115 0 |
+0.185 0 |
| >250~315 |
+0.052 0 |
+0.081 0 |
+0.130 0 |
+0.210 0 |
| >315~400 |
+0.0527 0 |
+0.089 0 |
+0.140 0 |
+0.230 0 |
Application:
1.Hydraulic Cylinder Tube---Used in the hydraulic cylinder of the heavy machinery, Cranes, excavator also forklifts. Material is various, mainly STKM-13CT, ST52, CK45 and 1020. We can work and get the mechanical property of the clients need and extended the life of the hydraulic cylinder.
2.SRB tube ----- Used in Elevator,buffer and Hydraulic Cylinder .This kind tube have a better roughness inner the tube, ra0.2-0.4um and can use directly in the hydraulic cylinder tube.
Range: ID 50-250mm and Length can work at most 6M.
3.Cold finished tube---- Widely Used. Processing range 30-300mm, biggest length is 11M.
