ASTM A519 1035 Seamless Carbon And Alloy Steel Mechanical Tubing For Hydraulic
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
| Minimum Order Quantity : | 0.5 Ton/Tons | Price : | negotiable |
|---|---|---|---|
| Packaging Details : | oil antirust In hexagonal bundles | Delivery Time : | 30-45 Days |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 60000 Tons per Year |
| Place of Origin: | China | Brand Name: | Torich |
|---|---|---|---|
| Certification: | ISO 9001-2008 ISO 14001 TS 16949 DNV LR | Model Number: | ASTM A106 |
|
Detail Information |
|||
| Product Name: | ASTM A106 Seamless Carbon Steel Pipe For High-Temperature Service | Type: | Seamless Steel Tubes |
|---|---|---|---|
| Surface: | Black Painted | Material: | 10#.20#.16Mn.A106(B,C).ST35-ST52 |
| Length: | 1-12m Or As Your Request | OD: | 6-1000mm |
| WT: | 1-80mm | Shape: | Round |
| High Light: | seamless steel pipe,precision stainless steel tubing |
||
Product Description
ASTM A106 Seamless Carbon Steel Pipe for High-Temperature Service
This covers seamless carbon steel pipe forhigh-temperature service in NPS !/8 to NPS 48 [DN 6 ItoDN 1200] inclusive, with nominal (average) wallthickness as given in ASME B 36.10M. It shall be permissibleto furnish pipe having other dimensions provided such pipecomplies with all other requirements of this specification. Pipeordered under this specification shall be suitable for bending,flanging, and similar forming operations, and for welding.When the steel is to be welded, it is presupposed that a weldingprocedure suitable to the grade of steel and intended use Orservice will be utilized.
Size: Outer Diameter: 6-1000 mm,Wall Thickness: 1- 80 mm,Length :1-12m or as your request
Application:High-Temperature Service
Material:10#.20#.16Mn.A106(B,C).ST35-ST52
Manufacture :Tubes shall be made by the seamless process and shall be cold drawn.
Heat Treatment:
1)Cold-drawn tubes shall be heat treated after the finalcold-draw pass at a temperature of 1 200F [640C] or higher toensure ductility satis factory for rolling into tube sheets and tomeet mechanical properties as specified.
2)If stress -relief anneal of the U-bends is specified, theanneal shall consist of heating the bent portion within a rangeof 1100 to 1200F [585 to 640C].
Outside diameter and wall thickness allow deviation mm
| sort code |
Manufacturing method |
Steel tube size | Allowable deviation | |
|
WHR (WHEX) |
Hot rolled(extruded)steel tube | OD | all | ±1%Dor±0.50(choose the bigger) |
| WT | ≤20 |
-15% +0.45 -10%S or –0.30 (choose the bigger) |
||
| ＞20 | ±10%S | |||
| WHE | Heat expand steel tube | OD | all | ±1%D |
| WT | all | ±15%S | ||
|
WCD (WCR) |
Cold drawn(rolled) steel tube | OD | ≤30 | ±0.20 |
| 30＜D≤50 | ±0.30 | |||
| ＞50 | ±0.8%D | |||
| WT | 1.5≤S≤3 |
+12.5% -10% S |
||
| ＞3 | ±10%S | |||
Bending of steel tube per meter
| OD/mm | Bending per meter(mm/m) |
| ≤15 | ≤1.5 |
| ＞15~30 | ≤2.0 |
| ＞30 or D≥351 | ≤3.0 |
The length of the steel tube bending should be not more than 1.5% of the steel tube length
