Carbon Steel Heat Exchanger Tubes Seamless Steel Tube Round Shape For Boiler / Heat Exchanger

Minimum Order Quantity : 5 tons Price : 800-1200 usd per ton
Packaging Details : Carbon Steel Heat Exchanger Tubes Seamless Steel Tube Round Shape For Boiler / Heat Exchanger,anti-rust oil protection in Hexagonal Bundles or Wooden Boxes Delivery Time : 30-45 days
Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram Supply Ability : 50000 tons per year
Place of Origin: Zhejiang,China Brand Name: TORICH
Certification: ISO9001,ISO14001,TS16949 Model Number: SA179, SA192, SA210, SA213 T5, T11,T22

Detail Information

Product Name: Carbon Steel Heat Exchanger Tubes Seamless Steel Tube Round Shape For Boiler / Heat Exchanger Keyword: Carbon Steel Heat Exchanger Tubes
Shape: Round Type: Seamless
Material: T5 T11, T12 ,A-1,C Application: For Boiler,heat Exchanger,Superheater Use
Brand: TORICH Length: Customized
OD: 12.7-127mm WT: 1-15mm
High Light:

carbon steel tube

,

high carbon steel tube

Product Description

Carbon Steel Heat Exchanger Tubes Seamless Steel Tube Round Shape For Boiler / Heat Exchanger

Applications: for Boilers,Superheaters,Steam linepipes of boilers


Size range: O.D.:12.7-127mm W.T.:1-15mm L: according to customer requirement





Steel Grade and Chemical Compositions:
Grade C Mn P S Si
A-1 ≤0.27 ≤0.93 ≤0.035 ≤0.035 ≥0.10
C ≤0.35 0.29-1.06 ≤0.035 ≤0.035 ≥0.10


Mechanical properties:

Grade Yield Point
Mpa(ksi)
Tensile Strength
Mpa(ksi)
Elongation
A-1 ≥255(37) ≥415(60) ≥30%
C ≥275(40) ≥485(70) ≥30%



Tolerance for OD and WT(SA-450/SA-450M)
OD in(mm) + - WT in(mm) + -
<1''(25.4) 0.10 0.10 ≤1.1/2''(38.1) 20% 0
1''~1.1''(25.4~38.1) 0.15 0.15 >1.1/2''(38.2) 22% 0
>1.1/2''~<2''(38.1~50.8 0.20 0.20
2''~<2.1/2''(50.8~63.5) 0.25 0.25
2.1/2''~<3''(63.5~76.2) 0.30 0.30
3''~<4''(76.2~101.6) 0.38 0.38
4''~<7.1/2''(101.6~190.5) 0.38 0.64
>7.1/2~9''(190.5~228.6) 0.38 1.14



Surface Condition:

Pickling or shot blasting, Passivated, Black Phosphating.



Tests and Inspection:

Flattening Test

Flaring Test

Hardness Test

Hydrostatic or Nondestruction Electric Test ( Eddy Current and Ultrasonic Testing)





buy  seamless medium-carbon steel boiler and superheater tubes manufacturercheap seamless medium-carbon steel boiler and superheater tubes suppliers



Reference Documents:

ASTM A450/A450M Specification for General Requirements for Carbon, Ferritic Alloy, and Austenitic Alloy Steel Tubes

ASTM A210 Seamless Medium Carbon Steel Heat Exchanger Tubes For Superheaters
