Product Details:
Payment & Shipping Terms:
|
| Product Name: | Seamless Carbon-Molybdenum Alloy Steel Boiler And Superheater Tubes | Keyword: | Boiler Tubes |
|---|---|---|---|
| Standard: | ASTM A209, ASTM A1016 | Surface: | Pickling |
| Material: | Grade T1, Grade T1a, Grade T1b | Shape: | Round |
| OD: | 12.7-127mm | WT: | 0.9-12.7mm |
| Length: | 4-12m | Usage: | Boiler And Superheater Tubes |
| STEEL GRADE AND CHEMICAL COMPOSITIONS | ||||||
| Seel Grade | C | Mn | P | S | Si | Mo |
| T1 | 0.10-0.20 | 0.30-0.80 | ≤0.025 | ≤0.025 | 0.10-0.50 | 0.44-0.65 |
| T1a | 0.15-0.25 | 0.30-0.80 | ≤0.025 | ≤0.025 | 0.10-0.50 | 0.44-0.65 |
| T1b | ≤0.14 | 0.30-0.80 | ≤0.025 | ≤0.025 | 0.10-0.50 | 0.44-0.65 |
| Mechanical Properties | |||||
| Seel Grade | Tensile strength(Mpa) | Yield Strength (Mpa) | δfixed (Pipe Segment S≥8mm vertical) | δfixed (S<8mm vertical) | δfixed (Round brilliant) |
| T1 | ≥380 | ≥205 | ≥30 | See note | ≥22 |
| T1a | ≥415 | ≥220 | ≥30 | See note | ≥22 |
| T1b | ≥365 | ≥195 | ≥30 | See note | ≥22 |
| Note: S<8mm vertical Elongation is the basic value minus 1.5%,per wall thickness minus 0.8mm | |||||
| HARDNESS | ||
| Seel Grade | HB S ≥5.1mm | HRB S≤ 5.1mm |
| T1 | ≤146 | ≤80 |
| T1a | ≤153 | ≤81 |
| T1b | ≤137 | ≤77 |
More products
Delivery condition and Heat treatment:
Cold Drawn Seamless and Hot Rolled Seamless need Heat treatment .minimum temperature is 650℃
If Delivery condition is annealing, isothermal annealing, normalizing+ tempering tempering minimum temperature is 650℃
Hot-finished tubes are heat treated at a temperature of 1200℉ (650℃) or higher.
Reference Documents:
ASTM A450/A450M Specification for General Requirements for Carbon, Ferritic Alloy, and Austenitic Ally Steel Tubes
ASTM A941 Terminology Relating to Steel, Stainless Steel, Related Alloys and Ferroalloys
