DIN 2393 St37-2 Welded Steel Tube Precision Cold Drawn Welded Steel Pipe For Sleeve
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
| Minimum Order Quantity : | 5Tons | Price : | USD700-1500/Ton |
|---|---|---|---|
| Packaging Details : | SSAW Steel Pipe packed in wooden boxes or hexagonal bundles in seaworthy packing. | Delivery Time : | 30-45work days |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 20000Tons per Year |
| Place of Origin: | ZHEJIANG, CHINA | Brand Name: | TORICH |
|---|---|---|---|
| Certification: | ISO9001, ISO14001, TS16949 | Model Number: | ASTM A333 |
|
Detail Information |
|||
| Standard: | ASTM, ASTM A333, ASTM A370, ASTM A999/A999M, ASTM A671, E23, E165, E709 | Material: | Gr1,Gr3,Gr4,Gr6,Gr7,Gr8,Gr9,Gr10,Gr11 |
|---|---|---|---|
| Surface: | Oiled | OD: | 6-420mm |
| WT: | 1-50mm | Usage: | Low Temperature Service With Notch Toughness |
| High Light: | welded steel pipe,electric resistance welded steel tube |
||
Product Description
Standard: ASTM A333, ASTM A370, ASTM A999/A999M, ASTM A671, E23, E165, E709
Size range: OD: 6-420mm
WT: 1-50mm
Length: 3-22m
Material: Q195, Q215, Q235, Q345, Gr1,Gr3,Gr4,Gr6,Gr7,Gr8,Gr9,Gr10,Gr11
Test: Transverse or Longfitudinal Tensile Test and Flattening Test
Impact Test
Chemical Requirements
| Element | Grade1 | Grade3 | Grade4 | Grade6 | Grade7 | Grade8 | Grade9 | Grade10 | Grade11 |
| C, max | 0.30 | 0.19 | 0.12 | 0.30 | 0.19 | 0.13 | 0.20 | 0.20 | 0.10 |
| Mn | 0.40-1.06 | 0.31-0.64 | 0.50-1.05 | 0.29-1.06 | 0.90 max | 0.90 max | 0.40-1.06 | 1.15-1.50 | 0.6 max |
| P, max | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.035 | 0.025 |
| S, max | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.015 | 0.025 |
| Si | -- | 0.18-0.37 | 0.08-0.37 | 0.10min | 0.13-0.32 | 0.13-0.32 | -- | 0.10-0.35 | 0.35max |
| Ni | -- | 3.18-3.82 | 0.47-0.98 | 0.40max | 2.03-2.57 | 8.40-9.60 | 1.60-2.24 | 0.25max | 35.0-37.0 |
| Cr | -- | -- | 0.44-1.01 | 0.30max | -- | -- | -- | 0.15max | 0.50max |
| Cu | -- | -- | 0.40-0.75 | 0.40max | -- | -- | 0.75-1.25 | 0.15max | -- |
| Al | -- | -- | 0.04-0.30 | -- | -- | -- | -- | 0.06max | -- |
| V | -- | -- | -- | 0.08 | -- | -- | -- | 0.12 | -- |
| Nb, max | -- | -- | -- | 0.02 | -- | -- | -- | 0.05 | -- |
| Mo, max | -- | -- | -- | 0.12 | -- | -- | -- | 0.05 | 0.50max |
| Co | -- | -- | -- | -- | -- | -- | -- | -- | 0.50max |
Characteristic:
Good concentricity High Precision
Good surface quality Stable quality
Good OD and ID tolerance Smooth Roughness
TORICH QUALITY ASSURANCE
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, and it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but you need to pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance , balance before shippment.
If you have another question, pls feel free to contact us
