A513-T5 Sae 1020 Or 1026 Drawn Over Mandrel Tubing ERW
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
| Minimum Order Quantity : | 3 tons | Price : | USD900-1200/ton |
|---|---|---|---|
| Packaging Details : | In bundles or carton boxes or wooden boxes | Payment Terms : | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability : | 6000 tons per year |
| Place of Origin: | Zhejiang,China | Brand Name: | TORICH |
|---|---|---|---|
| Certification: | ISO9001 TS16949 EN10204.3.1 | Model Number: | JIS G3445 STKM |
|
Detail Information |
|||
| Product Name: | Drawn Over Mandrel Steel Tube,Seamless Steel Tube,Electric Resistance | Key Word: | DOM Steel Tube |
|---|---|---|---|
| Grade: | STKM 11A STKM 12 (ABC) STKM 13(ABC) STKM 14(ABC) STKM 15(AC) Etc | Type: | DOM |
| Surface: | According To Customer's Request | Allplication: | Used For Mechanical,automotive,bicycle,etc |
| Brand: | Torich | OD: | 4-60mm |
| WT: | 0.5-7mm | Delivery Time: | 30-45 Days |
| High Light: | drawn over mandrel steel tube,drawn over mandrel steel tubing |
||
Product Description
Product Name:Carbon steel tubes for machine structural purposes
Appllication: Machine Auto competent Furniture Bicycle Mechanical parts Mechanical Elements machine elements
1.Grade
STKM 11A
STKM 12 (ABC)
STKM 13(ABC)
STKM 14(ABC)
STKM 15(AC) etc
Standard JIS G3445
2.OD:4-60mm,Wall thickness:0.5-7mm
3.Characteristic:The tubes are high precision in tolerance
4.Kindly advise heat treatment requirement if any.
HR CW SR A N HF
HR:hot rolled CW:cold worked SR:stress relieved A:annealed N:normalized HF: hot formed.
5.STKM 15A Chemical composition % max:C:0.25-0.35 S:0.35 Mn:0.30-1.00 P:0.04 S:0.04
Mechanical properties:min Tensile strength 470Mpa Yield Strength:275 Mpa Elongation:22%
| Tolerances on OD | |
| Division | Tolerance on OD |
| No.1 | under 50mm ±0.5mm 50mm or over ±1% |
| No.2 | under 50mm ±0.25mm 50mm or over ±0.5% |
| No.3 | under 25mm ±0.12mm 25mm or over to and excel.40mm ±0.15mm 40mm or over to and excel.50mm ±0.18mm 50mm or over to and excel.60mm ±0.20mm 60mm or over to and excel.70mm ±0.23mm 70mm or over to and excel.80mm ±0.25mm 80mm or over to and excel.90mm ±0.30mm 90mm or over to and excel.100mm ±0.40mm 100mm or over ±0.50% |
Note:1. For hot finished seamless steel tube, the outside diameter tolerance No.1 shall be applied.
2.The tolerance on outside diameter of quenched and tempered tubes shall be as agreed upon by the purchaser and manufacturer.
| Tolerances on WT | |
| Division | Tolerance on WT |
| No.1 | under 4mm +0.6mm -0.5mm 4mm or over +15%-12.5% |
| No.2 | under 3mm ±0.3mm 3mm or over ±10% |
| No.3 | under 2mm ±0.15mm 2mm or over ±8% |
Note: For the finished seamless steel tubes the tolerances No.1 shall be applied.
The tolerances on the tube length shall be in the range of 0 to+50mm.However,when tolerances outside this range are especially required,agreement shall be made between the purchaser and manufacturer.
(DOM)Drawn Over Mandrel :
The first stages of manufacturing : ERW ,but in the finishing stages : Entire flash weld is removed and the tube is clod drawn over a mandrel.which provides the tube with a better dimensional tolerances,good surface finish and the strongest weld strength achievable.
